Product features
1 ) using the advanced dual - CPU intelligent control technology, has the characteristics of high reliability and low failure rate
2 ) pure sine wave output, with strong load capacity and wide application range
3 ) have perfect protection function ( overload protection, internal temperature protection, output short circuit protection, input under voltage protection, input over voltage protection, etc. ). Greatly improving the reliability of the products
4 ) internal CPU centralized control and patch technology, making the volume is very small and light weight
5 ) the intelligent control of the cooling fan, using the CPU to control the working state of the cooling fan, greatly extend the service life of the fan, and save the electric energy and improve the working efficiency
6 ) working noise is small and high efficiency
Model | FG1500 12V | FG1500 24V | FG1500 48V | ||
Input | Voltage | 12V | 24V | 48V | |
Voltage range | 10-15V | 20-30V | 40-60V | ||
Low voltage alarm | 10V±0.5V | 20V±0.5V | 40V±0.5V | ||
Low voltage shutdown protection | 10V±0.5V | 20V±0.5V | 40V±0.5V | ||
Overvoltage shutdown protection | 15V | 30V | 60V | ||
Out put | Continuous power | 1500W | |||
Peak power | 2000W | ||||
Output waveform | Pure sine wave ( distortion rate ≤ 3 % ) | ||||
Output frequency | 50Hz±0.5 or 60Hz±0.5 | ||||
Output voltage | 100-110V/220-240V | ||||
Standard efficiency | 90 % ( full load ) | ||||
No-load current | <0.65A | <0.4A | <0.3A | ||
input terminal | Red / black copper terminal | ||||
Output socket | National standard / British / American | ||||
Cooling system | Intelligent temperature controlled cooling | ||||
Packing | Product size | 200x145x70mm | |||
Product weight | 1.2KG | ||||
Carton size | 460X310X210MM | ||||
Packing number | 4pcs | ||||
