Application:
Mainly used in office equipment, testing equipment, medical equipment, industrial automation equipment, household appliances, lighting systems, communication systems, etc.
Features:
MCU controlled circuit offering precision output
Zero cross transfer technology integrated
High efficienvy toroidal transformer
Dual Over load Protection(Fuse/MCB+MCU)
Relay failure detection
Super fast response time≤60ms
Individual switching power supply for 12Vdc
Technical Parameter
Specification | 500VA | 1000VA | 1500VA | 2000VA | 3000VA | 5000VA | 8000VA | 10000VA | |
Input | Voltage | See Table 1 | |||||||
Frequency | 50Hz / 60Hz | ||||||||
Output | Voltage | See Table 1 | |||||||
Capacity | 400W | 800W | 1200W | 1600W | 2400W | 4000W | 6400W | 8000W | |
Frequency | 50Hz / 60Hz | ||||||||
Protection | Low voltage | AC 184V±4V / AC 105V±4V | |||||||
Over voltage | AC 246V±4V / AC 142V±4V | ||||||||
Time Delay | 5 sec / 255 sec Selectable | ||||||||
Overload/ short circuit | Dual protection(fuse / MCB + MCU) | ||||||||
Packaging | PCS | 8 | 4 | 2 | 2 | 1 | 1 | ||
Kg | 26.8 | 18.5 | 20.4 | 25 | 22.6 | 29 | 18.5 | 20.5 | |
Paching(mm) | 470x185x245mm | 560x275x265mm | 640x380x350mm | 470x260x290mm | |||||
| |||||||||
Table 1 | Input | Output | Precision | ||||||
80-280V | 220V/230V/240V | 8% | |||||||
90-280V | |||||||||
100-280V | |||||||||
125-280V | |||||||||
140-260V | 5% | ||||||||
176-264V | |||||||||
80-145V / 85-150V | 110V/120V/130V | 5% / 10% | |||||||
